Technical Specifications
System Type
Low-voltage
Energy Storage Capacity
12 kWh
Nominal Voltage
51.2 V
Maximum Current
210 A @ 30 s
Maximum Power
10,752 W @ 30 s
Rated Current
115 A
Depth of Discharge (DoD)
95%
Communication
Pylontech protocol by default via CAN / RS485
Compatible Inverters
DEYE, Sofar, Growatt, Victron, Foxess, Solis, SMA, LUXPOWER, Sermatec, Renac, TBB POWER, GoodWe, IMEON, etc.
Parallel Connection Capability
Up to 16 units
Cycle Life (0.5C / 0.5C)
6,000 cycles @ 25°C, 80% DoD
Discharge Operating Temperature Range
-10°C to +55°C
Charge Operating Temperature Range
+5°C to +55°C
Installation Location
Indoor
Mounting Method
Wall-mounted or floor-standing
Weight
85 kg
Dimensions (W × D × H)
27 × 55 × 70 cm
