Technical Specifications
Nominal Voltage
12.8 V
Housing Material
Plastic (ABS)
Capacity
100 Ah
Voltage Range
10.8 V – 14.6 V
Recommended Maximum Current
100 A
Energy
1,280 Wh
Cycle Life
6,000 cycles @ 25°C, 70% DoD
Communication
Bluetooth
Cell Balancing Function
Yes
Discharge Operating Temperature Range
-20°C to +55°C
Charge Operating Temperature Range
-20°C to +55°C
Warranty
5 years
Terminal Type
M8
Ingress Protection
IP22
Weight
12 kg
Dimensions (L × W × H)
22.9 × 29.5 × 20.3 cm
